Forward SSH connections to GitLab running with Docker

In this tutorial I will explain how to redirect the git@ connections to your GitLab instance.

The network setup

Creating the `git` user on the host system

Ensure you have access to docker ps or add yourself to the docker group: sudo usermod -aG docker $USER && newgrp docker.

Then create the git user:

sudo useradd --uid $(docker exec gitlab id git -u) --gid $(docker exec gitlab id git -g) --home-dir /opt/gitlab/data --no-create-home git

Creating the scripts

Create the directory structure on the host system:

mkdir -p /opt/gitlab/embedded/service/gitlab-shell/bin

Create 3 scripts:

/opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell:

This script wraps the GitLab shell access.

#!/usr/bin/env sh

set -eu

/opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell-docker-exec gitlab-shell "$@"

/opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell-authorized-keys-check:

This script manages asking to GitLab if a key is authorized to access the SSH server.

#!/usr/bin/env sh

set -eu

/opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell-docker-exec gitlab-shell-authorized-keys-check "$@"

/opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell-docker-exec:

This script does all the magic of communicating with the GitLab container.

#!/usr/bin/env bash

set -e

if [[ "$1" == "gitlab-shell-authorized-keys-check" ]]; then
  SCRIPT="$1 git"
  shift
elif [[ "$1" == "gitlab-shell" ]]; then
  SCRIPT="$1"
  shift
else
  echo "'$1' unknown. Aborting."
  exit 1
fi

exec docker exec -i \
    --env SSH_CONNECTION="$SSH_CONNECTION" \
    --env SSH_CLIENT="$SSH_CLIENT" \
    --env SSH_TTY="$SSH_TTY" \
    --env GIT_SSH="$GIT_SSH" \
    --env SSH_ORIGINAL_COMMAND="$SSH_ORIGINAL_COMMAND" \
    gitlab \
    /opt/gitlab/embedded/service/gitlab-shell/bin/${SCRIPT} "$@"

Ensure gitlab-shell script is owned by git: sudo chown git:git /opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell
Make all 3 scripts executable: sudo chmod +x /opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell /opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell-authorized-keys-check /opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell-docker-exec

Check the scripts

I created the following checks:

sudo -u git /opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell-docker-exec gitlab-shell
# Only SSH allowed

and

sudo -u git /opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell-docker-exec gitlab-shell-authorized-keys-check
# Insufficient arguments. 1. Usage
#	gitlab-shell-authorized-keys-check <expected-username> <actual-username> <key>

Adjust the ssh server config

Finally in /etc/ssh/sshd_config you will need to add:

Match User git
    PermitEmptyPasswords no
    PasswordAuthentication no
    AuthorizedKeysCommand /opt/gitlab/embedded/service/gitlab-shell/bin/gitlab-shell-authorized-keys-check %u %k
    AuthorizedKeysCommandUser git

And then sudo service sshd restart

Testing the ssh connection

ssh git@instanceHostName

Example:

ssh [email protected]
PTY allocation request failed on channel 0
Welcome to GitLab, @williamdes!
Connection to 10.10.10.1 closed.

You can use ssh git@instanceHostName -vv to debug further. Be sure to add your SSH public key on your GitLab profile (SSH keys). You can check your agent has it loaded by using the command ssh-add -L. Bonus: it will display the public key to add on your GitLab account.
